Core, Essence, Moment, Playmaker or Beomaster 5 to B&O Beolink Passive, ML/ MCL Converter, MCL2P

Sounds Heavenly are proud to launch our new Beosound/BeoConnect Core, Essence, PlayMaker or Beomaster 5 to Beolink Passive Powerlink input RJ45 to DIN cable.  This also work to allow Beolink Passive (and regular unpowered speakers) to be used with any post-2013 B&O TVs that use RJ45 Powerlink outputs, including Beovision 11, 14, V1, Avant, Horizon, Eclipse and Horizon, as well Beosound Theatre sound bar.

B&O music streamers and TVs made since 2013 (with RJ45 outputs) cannot correctly activate a Beolink Passive amplifier when connected using regular RJ45 to Powerlink cables, as these products lack the required voltage triggers to activate the amplifier.  If you wish to use Beovox or other unpowered speakers with your B&O TV or music streamer via a Beolink Passive, MCL2P or ML/MCL Converter amplifier, you will need this specially wired cable to allow the amplifier to activate correctly.

These cables are perfect for connecting from the RJ45 Powerlink output of any 2013-on B&O TV or music system (as these products are unable to correctly drive a Beolink Passive via regular cables) to the Powerlink input socket of your Beolink Passive, ML/ MCL Converter or MCL2P amplifier.  If you are in any doubt about suitability, please ask.

Cable specifications:

• Screened High-Purity OFC Copper cable with Black outer sheath (2.5mm diameter)
• Audio conductors: 7 x 0.1mm stranded copper
• Screening conductor: 72 x 0.1mm stranded copper
• Neutrik/Rean metal cased 7-pin DIN plug with metal inner case and gold connectors (Passive/MCL2P end of cable)
• Shielded male 8 pin DIN plug with moulded plastic strain relief and gold contacts (Essence/Core end of cable)
• 0.1m RJ45 to female Powerlink mk.2 compatible clip-on adapter
